Flip-Flop Hoist Ring

Material: Forged High Strength Alloy Steel

Design Factor: 6:1, Magnetic Particle Inspected Per ASTM E1444.

Range of Movement: Pivot 180 degrees Under Load

Finish: Black Oxide Finish for corrosion resistance

High strength screws are 100% Magnaflux Inspected

All dimensions approximate – variations do not effect use or design factor.

HRFF-LINE-DRAWING-300px

Flip-Flop Hoist Rings
Part No.
with
Screws		Rated
Load
(lbs)		ABCDEFGHRInstallation
Torque
(ft-lbs)		Weight
w/ Screws
(lbs)
34030S20002″1-3/41″5/162-1/23/45/16 (2 PLCS)01/24-7.58
34035S25002-1/22-1/41-1/83/83-3/167/83/8 (2 PLCS)05/87-101.07
34040S50003″2-5/81-1/21/23-7/81-1/81/2 (2 PLCS)03/420-252.06
34045S120004″3-1/81-5/83/45-1/41-3/81/2 (4 PLCS)1-1/47/820-254.10
34050S200005″3-5/82-1/1616-3/161-7/85/8 (4 PLCS)1-1/4142-507.94
Flip-Flop Mounting Screws
Part No.Used P/NScrew ThreadScrew LengthWeight (lbs)
2381234030S5/16-181 1/4.04
2381334035S3/8-161 1/4.05
2380434040S1/2-132.14
2380534045S1/2-132 1/4.16
3364534050S5/8-112 3/4.50

*To obtain maximum load capacity, high strength screws must be used.
